Chief RLT3 Large Fit Tilt Display Wall Mount
Chief RLT3 Large Fit Tilt Display Wall Mount
In stock
SKU:RLT3
Couldn't load pickup availability
The Fit series RLT3 is a large tilt display wall mount for 43” to 86” typical display sizes and supports mounting patterns up to 915 x 450 mm. This next-generation design features 0.75” (19 mm) post-installation leveling, robust wall plate design supporting up to 200 lbs (90.7kg), 2” (51 mm) low-profile depth, up to 12° tilt, and UL and TUV safety standard approvals.
-
Low-profile 2” (51 mm) depth facilitates ADA compliance for typical AV design requirements
-
Easy to reach 0.75” (19 mm) post-installation leveling screw and 10” (254 mm) ball end hex-key included
-
Display can be tilted up to 12° to set the optimal viewing angle
-
Open wall plate allows for flexible positioning around power and data wall boxes
-
Supports display mounting patterns up to 915 x 450 mm
-
Rigid wall plate supports up to 200 lbs (90.7 kg) and has additional mounting slots for improved installation experience
-
Lateral shift with toolless GlideLock secures display to wall plate and allows perfect positioning of screen
-
Easy access magnetic quick-store release pullcords
-
Kickstand for easy access to power and signal connections
-
Theft deterrent security options (not included)
-
UL and TUV safety standards approved
