Hikvision DS-D42AM2 LED Multi-function Card LED Controllers

• Support network interface cascading between or behind the receiving card;
• Support infrared signal input.

Specification

General

• Storage Temperature-20 to + 60 °C (-4 to +140 °F)
• Working Temperature-10 to + 40 °C (+14 to +104 °F)
• Working Humidity10 to 90 %
• Storage Humidity10 to 90 %
• Package Dimensions (Width × Height × Thickness )317 × 82 × 242 mm (12.5 × 3.2 × 9.5 inch)
• Gross weight0.75 kg (1.7 lb)

Packing List

• multi-functional card × 1,
• infrared remote control × 1,
• power adapter × 1,
• outer package × 1

Control Card Parameter

• Sending Card DimensionW× H × D）200 × 42 × 126.7 mm (7.9 × 1.7 × 5.0 inch)
• Sending Card Weight0.70 kg (1.5 lb)

Electrical Parameter

• Power Supply12 VDC, 1A
• Peak Power8 W
• Average Power3 W
