Hikvision DS-C60S-04HO HDMI Output Board Video Wall Controllers

• The HDMI output board provides 4 HDMI ports and supports YUV 444 output.
• Supports HDMI composite audio output.

Specification

• Chassis
• Occupied SlotOutput slot

• Video Output
• Video Output Interface TypeHDMI 1.4
• Video Output Interfaces4
• Max. Video Output Resolution1080P
• Video Output Resolution

  1920 × 1200@60 Hz, 1600 × 1200@60 Hz, 1920 × 1080@60 Hz, 1680 × 1050@60 Hz,

  1280 × 720@60 Hz, 1280 × 1024@60 Hz, 1024 × 768@60 Hz

  Supports LED screen, custom resolution output, 60 Hz loading output, and 2.6 MP loading with width ranging from 144 to 4096 and height ranging from 144 to 2160.

• Loading Capacity for Video Output to LED

  Single mesh port with load 2600000,

  Width 288-3840;

  Height 288-2160;

• Audio Output
• Audio Output Interface TypeHDMI composite audio
• Audio Output Interfaces4
