This manually height-adjustable pylonsystem with pulley is compatible with all touch screen displays available on the market from 65" to 86" screen diagonal.
The two aluminum pylons are mounted on the wall and floor, the display brackets slides between these pylons by pulley and counter weight. This ensures that every user can work and present at the ergonomically best height. A handle is supplied as standard for height adjustment.
Features
Please indicate the model of the monitor when placing your order
Manually height-adjustable system with 2 pylons for floor and wall mounting
different pylon length available: 2600 mm or 2900 mm
center to floor distance at 2900 mm lenght of pylon = approx. 1500 mm - 2100 mm
center to floor distance at 2600 mm lenght of pylon = approx. 1150 mm - 1750 mm
Height adjustment with counterweights and pulley
All connections on the display are freely accessible
at least 600 mm stroke
Specifications
VESA Compatibility:
Horizontal: 200 mm - 800 mm
Vertical: 200 mm - 600 mm
Compatible Screen Size: 65" - 86"
Center to Floor Distance: Adjustable from 1500 mm to 2100 mm (59.1" - 82.7")
