Aurora Multimedia VLX-TCW2V-C-B 4K Audio/Video Distribution WallPlate

Aurora Multimedia VLX-TCW2V-C-B 4K IP Audio/Video Distribution Wall Plate - Black

Aurora Multimedia VLX-TCW2V-C-B 4K IP Audio/Video Distribution Wall Plate - Black is provides one of the most advanced IP Streaming solutions on the market utilizing Aurora's IPBaseT technology, which synergizes various IP/AV standards to work together as one. It is the industry's first 4K UHD transceiver with only 1.5 frame (25ms) latency and visually lossless compression.

The VLX-TCW2V has 1 VGA and 1 HDMI port. Using a transmitter (encoder) and receiver (decoder), respectively, used to be the standard - until now. The VLX-TCW2 Series can be set up as either one to make installation, inventory, and troubleshooting easier.

Features:

• 4K visually lossless over 1Gbps network
• Low 1.5 frame latency
• 1080p to 4K, 4K to 1080p scaling
• HDMI 2.0/HDCP 2.2
• Unlimited scalability (based on network topology)
• Videowall with image rotation
• PoE (Power over Ethernet)
• Stereo line I/O
• RS-232 and IR Control Ports
• Auto sense switching
• USB 2.0 Host and Device Ports
• Dante IP audio option
• Warrenty: 60 Months

Specifications:

• Technical
• Compression: 8:1
• Latency 1.5 Frames (25ms)
• Scaling: 1080p to 4K, 4K to 1080p
• HDMI Inputs: 2 HDMI 2.0/HDCP2.2
• HDMI Outputs: 1 HDMI 2.0/HDCP2.2
• VGA/YPbPr Inputs: 1 15 Pin HD Female
• Audio Analog: Stereo Line In/Out (3.5mm TRS)
• 1G Copper Ethernet: RJ-45
• LAN: RJ-45 10/100/1000M PoE (PSE)
• Video Bandwidth: 340MHz
• Video support: Up to 4K2K 4:2:0 @60Hz
• Audio support: Up to 32 channels & Break-away Capable
• RS-232: 2 qty Up to 115k Baud (3.5mm TRS)
• IR: Bi-Directional (3.5mm TRS)
• USB Connector: 1 USB 2.0 Type A, 1 USB 2.0 Type B 2 USB 1.1 Type A
• Expansion Port: Dante Option
• Interface: IR or Keypad via OSD, Webserver
• Mechanical
• Housing: Aluminum
• Dimensions (LxWxH): 2 Gang 3.728" x 2.83" (4.331" with tabs) x 1.404"
• Weight: 2.5 lbs
• Mounting: Wall-mounting Decora 2 Gang
• Power supply: 48V DC (2 pin Euro) or 1G PoE
• Power consumption: 9 Watts
• Operation temperature: 32 - 104˚F
• Storage temperature: -4 - 140˚F
• Relative humidity: 20 - 90% RH (no condensation)

Downloads:

• User Guide
• Spec Sheet
